Engine	25 BHP, KIRLOSKAR Make Model : HA 294
Air Compressor	Standard Make.
Clutch	Standard Make.
Burner For Storage Tank	43000 Kael / Hr. - Gun Type.
Hand Torch Burner	26000 Kael / Hr.
Bitumen Pump	Spring Loaded 290 LPM @ 6 BAR.
Pneumatic Cylinder	AIR pneumatics
Temperature Meter	Standard Make.
Pressure Gauge	Standard Make.
Bearing Pedestal	Standard Make.
V – Belt	Fanner or Equivalent.
Valves, Fittings	Standard Make.
Hose Pipes	Standard Make.
Nozzles 19 nos. & Ball Valves	Standard Make.
Bitumen Tank	“U” Shaped, 50 MM. Thicknesses. 50 MM Glass wool Insulated.
Tank Plate Thickness.	4 MM
Burner pipe	10” Inch. Thickness 8 MM. And Inside Pipe 8”x 5 MM Thickness.
Tank Details	QEBS- 6000
Length – L x W x H	3000 x 1700 x 1650
Capacity	6000 liters
Main hole Dia.	600 MM
Required Chassis Length	4880 MM
TRUCK :-TATA, LEYLAND, EICHER	16 fit to 18 fit
TRUCK TYRE SZE	1000.20
